DuraMac Hydrogen Fuel Cell Chassis DFD4250GLFCEV5

The hydrogen fuel cell system, used as an energy source and paired with multiple hydrogen cylinders, offers the advantages of long driving range and short refueling times. Its long-range driving range and power performance meet market operational needs, achieving hydrogen consumption of less than 0.12 kg/km on flat roads and an overall road economy of less than 0.15 kg/km (fully loaded with a 49-ton loader), placing it at the forefront of the industry.

The power battery utilizes Tianjin Mengyuanli’s high-performance batteries, which account for over 50% of domestically announced sales, ensuring sustained high-power operation on mountainous roads.

The vehicle’s electrical connectors are all top-tier domestic or imported, ensuring a sealed and waterproof connection, enhancing the reliability and safety of the electrical components.

Technical Specifications

Size: 7490*2550*3820mm
Wheelbase: 3800+1350mm
Wheel Track(Front/Rear): 2036/1860mm
Front/Rear Suspension: 1530/810mm
Max. Overall Weight: 25000KG
Max. Speed: 85km/h
Passenger Capacity: 2
Rated Power: 215KW
Range: 350km
Front Axle: HanDe 5.5T axle
Middle/Rear Axle HanDe 11.5T axle
Transmission:  6AMT

coming soon

coming soon

coming soon

DuraMac

DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.

FIND MORE

Fast Gear

The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.

FIND MORE

EV Truck

Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.

FIND MORE

DANA Axle

Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.

FIND MORE

Datong Gear

The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Model

Size

Wheelbase

Max. Overall Weight

Max. Speed

Rated Power

Passenger Capacity

DFD4250GLFCEV5 7490 * 2550 * 3820 mm 3800+1350mm 25000KG 85 km/h 215 KW 2,3
DFD4250GLFCEV2 7830 * 2550 * 3820 mm 4050+1350mm 25000KG 85 km/h 236 KW 2
DFD1180GLFCEVJ3 9400 * 2500 * 3160 mm 5800mm 18000KG 85 km/h 120 KW 2
DFD1180GLFCEVJ1 10600 * 2530 * 2780 mm 7150mm 18000KG 79 km/h 215 KW 2
——END——

Basic information of DuraMac DFD4250GLFCEV5 motor

Motor Model TZ420XSTKQ001 Motor Manufacturer Dongfeng Teqi (Shiyan) Bus Co., Ltd.
Position/Fuel Type Mid-mounted/Hydrogen Fuel Cell Motor Type Permanent Magnet Synchronous Motor
Rated/Peak Power of Motor (kw) 215/360 Rated/Peak Torque (N.m) 1200/2400
Total Battery Capacity (kWh) 100.9 Mengguli Lithium Manganese Battery Driving Range (40km/h Constant Speed Method) 350km
Fuel Cell Brand Shanxi Kunpeng Rated/Peak Power of Fuel Cell (kw) 125/126
Hydrogen Cylinder Volume (L) Zhejiang Lanneng 8×210 = 1680L
——END——

Standard / Optional Configuration

Item Standard Configuration Optional Configuration
Frame DL710 940 variable, 860mm width × 300mm height × thickness (8 + 4)
Front Axle Hande Axle 5.5T Qingdao Qite Axle, Dongfeng Dana Axle
Middle/Rear Axle Hande Axle 11.5T Qingdao Qite Axle, Dongfeng Dana Axle
Transmission 6AMT
Suspension Multi – leaf spring 9/10, rear balance suspension structure
Steering Hydraulic power steering
Brake Air brake, dryer, condenser, ESC, self – adjusting arm, wear alarm, ADAS
Tire 12R22.5 – 18PR (No spare tire) Optional 12.00R20 18PR, 11.00R20 – 18PR, 315/80R22.5 – 18PR
Air Compressor Oil – free piston
Others Electronic fan, internal spline structure power take – off
——END——

Chassis Parameters and Configuration

Item Standard Configuration Optional Configuration
Body Structure High – roof cab
Body Suspension Tilt Full – floating front and rear suspension with mechanical shock absorption, electric – hydraulic tilt Full – floating rear suspension with airbag shock absorption
Interior Decoration Laminate composite material
Central Control and Door Locks Central door locks
Side Windows Electric lifting
Windshield Front windshield laminated glass
Rearview System Inner rearview mirror, steel – frame rod – type rearview mirror
Air – conditioning System Cab heating and cooling air – conditioning
Heating System Cab heating and cooling air – conditioning
Defroster Instrument panel blower structure for defrosting
Audio – visual System MP3 player,
Lamps Combined headlamps (with light adjustment device)
Wiper Forward – sweeping electric wiper
Seats 2 seats, airbag – suspended driver’s seat
Paint Domestic plain paint Metallic paint
Others Air horn, mechanical power – off switch, OBD socket, heavy – duty vehicle remote terminal T – BOX, Beidou satellite positioning travel recorder with printing function. Reversing monitoring system, ETC on – board device.
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
