Size: 8410*2550*3245/3300/3400 mm
Wheelbase: 4500 mm
Max. Overall Weight: 11500 kg
Max. Speed: 89 km/h
Rated Power: 120/185 kW
Passenger Capacity: 2,3
DuraMac
DuraMac is a sub-brand of SinoMac Group focusing on automotive applications. It is responsible for the global automotive business and provides customers with one-stop, high-quality solutions, leveraging more than 15 years of industry experience. We provide a variety of vehicle options, including electric, fuel, hydrogen cell Buses and school buses, etc., to meet different needs such as urban buses, long-distance transportation and student pick-up. Our automotive product line includes FAST, Allison, Datong transmissions, Dana axles, Cummins, Deutz, Komatsu, Perkins, Caterpillar engines, as well as drive motors, cab assemblies, etc., and can provide flexible and customized services for top customers. From initial contact to final cooperation of each project, DuraMac always shows its professional attitude and service to every honored customer and esteemed company. DuraMac is always here to respond to every inquiry from you.
DuraMac
DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.
Fast Gear
The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.
EV Truck
Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.
DANA Axle
Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.
Datong Gear
The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Find Duramac chassis by Series
This is the list of all Duramac chassis series for Pure Electric Truck, Pure Electric Chassis, Hydrogen Fuel Cell Chassis, Fuel Chassis, Truck Parts and Powertrain.
Pure Electric Truck
| 270 kW | ||||||||
| 315kW | ||||||||
| 220 kW | ||||||||
| 215 kW | ||||||||
| 215 kW | ||||||||
| 100 kW | ||||||||
| 280 kW | ||||||||
| 280 kW | ||||||||
| 240 kW | ||||||||
| 120 kW | ||||||||
| 248 kW | ||||||||
| 215 kW | ||||||||
|
Model Power/kW |
50 | 100 | 150 | 200 | 250 | 300 | 350 | 400 |
| Pure Electric Truck Catalogue | ||||||||
EQ1310GLEVJ | Pure Electric Truck
Size: 9040*2550*3400 mm
Wheelbase: 1700+3450+1350 mm
Max. Overall Weight: 31000 kg
Max. Speed: 85 km/h
Rated Power: 240 kW
Passenger Capacity: 2,3
EQ1310GLEVJ1 | Pure Electric Truck
Size: 9310*2535*3150/3100 mm
Wheelbase: 1850+3200+1350 mm
Max. Overall Weight: 31000 kg
Max. Speed: 85 km/h
Rated Power: 280 kW
Passenger Capacity: 2,3
EQ1310GTBEV | Pure Electric Truck
Size: 11900*2550*3000 mm
Wheelbase: 1850+4600+1350 mm
Max. Overall Weight: 31000 kg
Max. Speed: 89 km/h
Rated Power: 280 kW
Passenger Capacity: 2
EQ3120TTBEV | Pure Electric Truck
Size:6550/6670 * 6870*2350 * 2400*2670 mm
Wheelbase: 3600/3800 mm
Max. Overall Weight: 11995 kg
Max. Speed: 85 km/h
Rated Power: N/A
Passenger Capacity: 2,3
EQ3180GTBEV1 | Pure Electric Truck
Size: 6450/6550/6650/6750*2360/2850/2450/2500*2750/2850/2900/2950 mm
Wheelbase: 3750 mm
Max. Overall Weight: 11995 kg
Max. Speed: 85 km/h
Rated Power: 100 kW
Passenger Capacity: 2,3
EQ4250GLBEV1 | Pure Electric Truck
Size: 7490*2550*3410 mm
Wheelbase: 3800+1350 mm
Max. Overall Weight: 25000 kg
Rated Power: 215 kW
Max. Speed: 85 km/h
Passenger Capacity: 2
EQ4251GTBEV | Pure Electric Truck
Size: 7490*2550*3350/3410 mm
Wheelbase: 3800+1350 mm
Max. Overall Weight: 25000 kg
Rated Power: 220 kW
Max. Speed: 85 km/h
Passenger Capacity: 2
EQ4251GTBEV1 | Pure Electric Truck
Size: 7410*2550*3250 mm
Wheelbase: 3800+1350 mm
Max. Overall Weight: 25000 kg
Rated Power: 315 kW
Max. Speed: 85 km/h
Passenger Capacity: 2
EQ4251GTBEV2 | Pure Electric Truck
Size: 7660*2550*2980 mm
Wheelbase: 4050+1350 mm
Max. Overall Weight: 25000 kg
Rated Power: 270 kW
Max. Speed: 85 km/h
Passenger Capacity: 2
DFD4250GLBEV | Pure Electric Truck
Size: 7590 * 2559 * 3330 mm
Wheelbase: 3900+1350 mm
Max. Overall Weight: 25000 kg
Max. Speed: 85 km/h
Rated Power: 215 kW
Passenger Capacity: 2
EQ5250ZLJTBEV | Pure Electric Truck
Size: 8630*2550*3280 mm
Wheelbase: 2050+3100 mm
Max. Overall Weight: 25000 kg
Max. Speed: 89 km/h
Rated Power: 215 kW
Passenger Capacity: 2
EQ5310ZLJTBEV | Pure Electric Truck
Size: 11750*2550*3430 mm
Wheelbase: 1950+4750+1400 mm
Max. Overall Weight: 31000 kg
Max. Speed: 85 km/h
Rated Power: 248 kW
Passenger Capacity: 2
Pure Electric Chassis
| 215 kW | ||||||||
| 240 kW | ||||||||
| 50 kW | ||||||||
| 100 kW | ||||||||
| 215 kW | ||||||||
|
Model Power/kW |
50 | 100 | 150 | 200 | 250 | 300 | 350 | 400 |
EQ1070FTEVJ(N12) | Pure Electric Chassis
Size: 5998*2060*2730 mm
Wheelbase: 3650 mm
Rated Power: 50 kW
Max. Overall Weight: 6550 kg
Max. Speed: 60 km/h
Passenger Capacity: 2
EQ1180EVJ1 | Pure Electric Chassis
Size: 8350*2430*3400/3300/3245/3185 mm
Wheelbase: 4500 mm
Rated Power: 100 kW
Max. Overall Weight: 18000 kg
Max. Speed: 89 km/h
Rated Capacity: 2,3
EQ1310GLEVJ | Pure Electric Chassis
Size: 9040*2550*3400 mm
Wheelbase:1700+3450+1350 mm
Rated Power: 240 kW
Max. Overall Weight: 31000 kg
Max. Speed: 85 km/h
Passenger Capacity: 2
EQ4250GLBEV1 | Pure Electric Chassis
Size: 7590 * 2559 * 3330 mm
Wheelbase: 3900+1350 mm
Rated Power: 215 kW
Max. Overall Weight: 25000 kg
Max. Speed: 85 km/h
Passenger Capacity: 2
DFD4250GLBEV | Pure Electric Chassis
Size: 7590 * 2559 * 3330 mm
Wheelbase: 3900+1350 mm
Rated Power: 215 kW
Max. Overall Weight: 25000 kg
Max. Speed: 85 km/h
Passenger Capacity: 2
Hydrogen Fuel Truck
| 220 kW | ||||||||
| 220 kW | ||||||||
| 236 kW | ||||||||
| 220 kW | ||||||||
| 220 kW | ||||||||
|
Model Power/kW |
50 | 100 | 150 | 200 | 250 | 300 | 350 | 400 |
EQ4251GTFCEV | Hydrogen Fuel Truck
Size: 7490*2550*3740/3790 mm
Wheelbase: 3800+1350 mm
Rated Power: 220 kW
Max. Overall Weight: 25000 kg
Max. Speed: 85 km/h
Passenger Capacity: 2
EQ4251GTFCEV2 | Hydrogen Fuel Truck
Size: 7830*2550*3820/3780 mm
Wheelbase: 4050+1350 mm
Rated Power: 220 kW
Max. Overall Weight: 25000 kg
Maximum Speed: 85 km/h
Rated Capacity: 2
DFD4250GLFCEV2 | Hydrogen Fuel Truck
Size: 7830*2550*3820/3780 mm
Wheelbase: 4050+1350 mm
Rated Power: 236 kW
Max. Overall Weight: 25000 kg
Maximum Speed: 85 km/h
Rated Capacity: 2
DFD4250GLFCEV6 | Hydrogen Fuel Truck
Size: 7740*2550*3740/3790 mm
Wheelbase: 4050+1350 mm
Rated Power: 220 kW
Max. Overall Weight: 25000 kg
Maximum Speed: 85 km/h
Rated Capacity: 2
DFD4250GLFCEV8 | Hydrogen Fuel Truck
Size: 7490*2550*3740/3790 mm
Wheelbase: 3800+1350 mm
Rated Power: 220 kW
Max. Overall Weight: 25000 kg
Maximum Speed: 85 km/h
Rated Capacity: 2
Hydrogen Fuel Cell Chassis
| 215 kW | ||||||||
| 236 kW | ||||||||
| 120 kW | ||||||||
| 215 kW | ||||||||
|
Model Power/kW |
50 | 100 | 150 | 200 | 250 | 300 | 350 | 400 |
DFD1180GLFCEVJ1 | Hydrogen Fuel Cell Chassis
Size: 10600*2530*2780 mm
Wheelbase: 7150 mm
Max. Overall Weight: 18000 kg
Rated Power: 215 kW
Max. Speed: 79 km/h
Passenger Capacity: 2
DFD1180GLFCEVJ3 | Hydrogen Fuel Cell Chassis
Size: 9400*2500*3160 mm
Wheelbase: 5800 mm
Max. Overall Weight: 18000 kg
Rated Power: 120 kW
Max. Speed: 85 km/h
Passenger Capacity: 2
DFD4250GLFCEV2 | Hydrogen Fuel Cell Chassis
Size: 7830*2550*3820 mm
Wheelbase: 4050+1350 mm
Max. Overall Weight: 25000 kg
Rated Power: 236 kW
Max. Speed: 85 km/h
Passenger Capacity: 2
DFD4250GLFCEV5 | Hydrogen Fuel Cell Chassis
Size: 7490*2550*3820 mm
Wheelbase: 3800+1350 mm
Max. Overall Weight: 25000 kg
Rated Power: 215 kW
Max. Speed: 85 km/h
Passenger Capacity: 2,3
Fuel Chassis
| 120 kW | ||||||||
| 100 kW | ||||||||
| 110 kW | ||||||||
|
Model Power/kW |
50 | 100 | 150 | 200 | 250 | 300 | 350 | 400 |
EQ1150GT6DJ | Fuel Chassis
Size: 5780*2050*2390 mm
Wheelbase: 3310 mm
Max Overall Weight: 14000 kg
Max Speed: 110 km/h
Engine Model: Cummins D6.7 NS6B 320
Passenger Capacity: 2,3
EQ2070FL6DJ | Fuel Chassis
Size: 5780*2050*2390 mm
Wheelbase: 3310 mm
Max. Overall Weight: 7000 kg
Max. Speed: 100 km/h
Engine Model: NAVECO SOFIM8140.43S6
Passenger Capacity: 2,3
EQ2130FT6DJ | Fuel Chassis
Size: 5995*2500*3065 mm
Wheelbase: 3800+1350 mm
Max. Overall Weight: 13000 kg
Max. Speed: 120 km/h
Engine Model: D6.7NS6B320
Passenger Capacity: 2
Truck Parts
Products Not Available
The relevant products still under developing or waiting to be update, please contact our sales team for latest updates.
Powerpack
EV Powertrain
New energy commercial vehicle powertrain with e-axles, motors and controllers.
Axle
Axles integrate DuraMac, Dongfeng Dana, DANA and other renowned brands, matched with Fast Gear, Datong Gear and other high-quality gearboxes. Covering traditional fuel and new energy electric truck solutions, they fit light, medium, heavy-duty trucks, buses, cranes and other engineering special vehicles, forming an efficient, diversified commercial vehicle supporting system.
Transfer Case
Core power distribution unit for 4WD vehicles, ideal for engineering transport.
Transmission
Full-range transmissions for commercial vehicles, meeting diverse power needs.
Engine
One-stop global powertrain solutions for diverse industrial applications.
