DuraMac Pure Electric Truck EQ1310GLEVJ1
The standard configuration uses a 350kWh EVE Energy ultra-high capacity power battery with a low failure rate. The mixer truck boasts a range exceeding 200km under comprehensive operating conditions, sufficient for daily urban concrete transportation without requiring recharging, thus improving operational efficiency.
All electrical connectors utilize top-tier domestic or imported components to ensure sealing and waterproofing at the connection points, enhancing the reliability and safety of electrical components.
The vehicle employs a high-strength DL710 material 8+8+6mm frame and a mature and stable suspension system, providing wide load-bearing capacity and high safety.
Technical Specifications
| Size: | 9040*2550*3400mm |
| Cargo Box Dimensions: | (5800-6200)*2350*1500mm |
| Wheelbase: | 1850+3200+1350mm |
| Front Overhang/Rear Overhang: | 500/1410mm |
| Approach/Departure Angle: | 19°/23° |
| Curb Weight: | 12000KG |
| Maximum Total Mass: | 31000KG |
| Rated Capacity: | 2 |
| Maximum Speed: | 85km/h |
| Track Width: | 2036/2036/1860/1860mm |
DuraMac
DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.
Fast Gear
The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.
EV Truck
Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.
DANA Axle
Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.
Datong Gear
The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
- Pure Electric Truck Series
- Power System Parameters
- Standard / Optional Configuration
- Chassis Parameters and Configuration
Model |
Size |
Wheelbase |
Max. Overall Weight |
Max. Speed |
Rated Power |
Passenger Capacity |
| EQ1310GLEVJ1 | 9310*2535*3150/3100mm | 1850+3200+1350mm | 31000KG | 85km/h | 280KW | 2,3 |
| EQ1310GTBEV | 11900*2550*3000mm | 1850+4800+1350mm | 31000KG | 85km/h | 280KW | 2 |
| EQ3120TTBEV | 6550/66706870235024002670mm | 3900/3800mm | 11995KG | 85km/h | N/A | 2,3 |
| EQ3180GTBEV1 | 6450/6550/6850/6750*2360/2850/2450/2500… | 3750mm | 11995KG | 85km/h | 100KW | 2,3 |
| DFD4250GLBEV | 7590*2559*3330mm | 3800+1350mm | 25000KG | 85km/h | 215KW | 2 |
| EQ4250GLBEV1 | 7590*2559*3330mm | 3800+1350mm | 25000KG | 85km/h | 215KW | 2 |
| EQ4251GTBEV | 7490*2550*3350/3410mm | 3800+1350mm | 25000KG | 85km/h | 220KW | 2 |
| EQ4251GTBEV2 | 7660*2550*2980mm | 4050+1350mm | 25000KG | 85km/h | 270KW | 2 |
| EQ4251GTBEV1 | 7410*2550*3250mm | 3800+1350mm | 25000KG | 85km/h | 315KW | 2 |
| EQ1310GLEVJ | 9040*2550*3400mm | 1700+3450+1350mm | 31000KG | 85km/h | 240KW | 2,3 |
| EQ1180GTEV | 8410*2550*3245/3300/3400mm | 4500mm | 11500KG | 89km/h | 120/185KW | 2,3 |
| EQ5310ZLJTBEV | 11750*2550*3430mm | 1950+4750+1400mm | 31000KG | 85km/h | 248KW | 2 |
| EQ5250ZLJTBEV | 8630*2550*3280mm | 2050+3100mm | 25000KG | 89km/h | 215KW | 2 |
| ——END—— | ||||||
Basic information of DuraMac EQ1310GLEVJ1 motor |
|||
| Motor Model | TZ420XST504 | Motor Manufacturer | Shandong Zhonglian Nengchuang Power Technology Co., Ltd. |
| Position / Fuel Type | Mid-mounted / Battery Swapping | Motor Type | Permanent Magnet Synchronous Motor |
| Motor Rated / Peak Power (kW) | 280/410 | Rated / Peak Torque (N·m) | 1400/2500 |
| Total Battery Capacity (kWh) | 350 18Wh (EVE Power) | Driving Range (40km/h Constant Speed Method) | 150km |
| Vehicle Announcement and Batch | 357 | Recommendation / Exemption | —- |
| National Subsidy Level Amount (10,000 CNY) | —- | ||
| ——END—— | |||
Standard / OptionalConfiguration |
||
| Item | Standard Configuration | Optional Configuration |
| Frame | 5170 Front 340 Rear 360 860 Width × 300 Height × Thickness (8+5) | – |
| Front / Second Axle | Dana Axle 5.5T | – |
| Middle / Rear Axle | Dana Axle 11.5T | – |
| Transmission | 4AT | – |
| Suspension | Multi-leaf Spring, 10/10/13 (Heavy-duty Version) | – |
| Steering | Hydraulic Power Steering | – |
| Braking | Air Brake, Dryer, Condenser, ABS, Automatic Adjuster, Wear Alarm | – |
| Tires | 11.00R20 18PR | 12.00R20 18PR |
| Air Compressor | Oil-free Piston Machine | – |
| Others | Electronic Fan, Power Take-off (PTO) | – |
| ——END—— | ||
Chassis Parameters and Configuration |
||
| Item | Standard Configuration | Optional Configuration |
| Body Structure | Fully Welded Steel Hood Single-axle Standard Roof Cab | – |
| Body Suspension and Tilt | Semi-floating Front and Rear Suspension with Mechanical Damping, Electric Hydraulic Tilt | – |
| Interior Trim | Laminated Composite Material | – |
| Central Control and Door Locks | Central Door Locks | – |
| Side Windows | Electric Lifting | – |
| Windshield | Front and Rear Laminated Glass | – |
| Rearview System | Interior Rearview Mirror, Steel Frame Asymmetric Manual Rod-type Rearview Mirror | – |
| Air Conditioning System | Cab External Swing Air Conditioning | – |
| Heating System | Cab External Swing Air Conditioning | – |
| Defroster | Instrument Panel Blower Structure Defroster | – |
| Audio-visual System | MP3 Player | – |
| Lamps | Combined Headlamps (with Light Adjustment Device) | – |
| Windshield Wipers | Forward Sweeping Electric Windshield Wipers | – |
| Seats | 2-3 Seats, Mechanical Damping Driver’s Seat | – |
| Paint | Domestic Plain Color Paint | – |
| Others | Air Horn, Mechanical Power Cut-off Switch, OBD Socket, New Energy Remote Terminal T-BOX, Beidou Satellite Positioning Driving Recorder with Printing | – |
| ——END—— | ||
