Fuel Chassis

DuraMac fuel chassis span 4×2, 6×2 and 8×4 layouts, with GVW 12–43 t and wheelbases 3.6–6.2 m. All platforms are powered by Euro-6 Cummins, Yuchai or Nissan Diesel engines rated 132–400 kW and 900–1900 N·m, coupled to 9- or 16-speed FAST/ZF gearboxes. The 280–300 mm high-strength, single-stamped frame is offered with multi-leaf or air suspension, PTO, hydraulic pump and body-electric interfaces, enabling rapid conversion into tankers, tippers, crane trucks, wreckers and 20+ other specials.

Advantages of Fuel Chassis

The Euro-6 powertrain delivers 46 % thermal efficiency and 8 % lower fuel consumption than Euro-5; an aluminium tank, air tanks and flywheel housing together save 450 kg, adding the same in payload. Modular interfaces cut body-build time by 30 % while keeping full type-approval, emission and 3-C coverage. A 1,200-strong service network provides 24-hour parts delivery and a 5-year/500 000 km warranty on core components, lowering total cost of ownership by 10–15 %—giving operators “more fuel-saving, more payload, faster up-fit and peace of mind”.

DuraMac

DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.

FIND MORE

Fast Gear

The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.

FIND MORE

EV Truck

Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.

FIND MORE

DANA Axle

Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.

FIND MORE

Datong Gear

The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Find Fuel Chassis by Types

This is the list of all Types of Fuel Chassis.

EQ2130FT6DJ 120 kW
EQ2070FL6DJ 100 kW
EQ1150GT6DJ 110 kW

Model

Power/kW

50 100 150 200 250 300 350 400
EQ2130FT6DJ | Fuel Chassis

EQ2130FT6DJ | Fuel Chassis

Size: 5995*2500*3065 mm
Wheelbase: 3800+1350mm
Max. Overall Weight: 13000KG
Max. Speed: 120 km/h
Engine Model: D6.7NS6B320
Passenger Capacity: 2

EQ2070FL6DJ | Fuel Chassis

EQ2070FL6DJ | Fuel Chassis

Size: 5780*2050*2390 mm
Wheelbase: 3310mm
Max. Overall Weight: 7000KG
Max. Speed: 100 km/h
Engine Model: NAVECO SOFIM8140.43S6
Passenger Capacity: 2,3

EQ1150GT6DJ | Fuel Chassis

EQ1150GT6DJ | Fuel Chassis

Size: 5780*2050*2390mm
Wheelbase: 3310mm
Max Overall Weight: 14000KG
Max Speed: 110 km/h
Engine Model: Cummins D6.7 NS6B 320
Passenger Capacity: 2,3
