Pure Electric Chassis

DuraMac has built a full-range electric chassis portfolio spanning urban delivery, regional distribution and mining/port platforms. Wheelbases from 3.8 m to 7.1 m are available in 4×2, 6×2 and 8×4 configurations, accepting CATL or Ganfeng LFP packs of 55–423 kWh that support both plug-in and battery-swap modes. Unified GB/T 36881 interfaces allow box, stake, dump, tank or crane superstructures to be bolted on with zero welding, giving body-builders “one chassis, multiple models” in days instead of weeks.

Advantages of Pure Electric Chassis

The “e-axle + under-floor battery + air/leaf-spring options” layout drops centre-of-gravity by 120 mm and cuts kerb weight by 8 %, trimming energy use to 1.1 kWh/km; swap version exchanges a 423 kWh pack in 5 min, while charge version tops 20-80 % in 40 min, enabling two-shift 20-hour operation. IP68 & IP6K9K sealed packs are validated from -40 °C to 60 °C and resist fire for 30 min; OTA and V2G ports are ready for future grid services. TCO falls 25-35 % versus diesel, delivering “more payload, faster turns, lower cost” green logistics.

DuraMac

DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.

FIND MORE

Fast Gear

The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.

FIND MORE

EV Truck

Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.

FIND MORE

DANA Axle

Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.

FIND MORE

Datong Gear

The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Find Pure Electric Chassis by Types

This is the list of all Types of Pure Electric Chassis.

EQ4250GLBEV1 215 kW
EQ1310GLEVJ 240 kW
EQ1070FTEVJ(N12) 50 kW
EQ1180EVJ1 100 kW
DFD4250GLBEV 215 kW

Model

Power/kW

50 100 150 200 250 300 350 400

EQ1310GLEVJ | Pure Electric Chassis

EQ1310GLEVJ | Pure Electric Chassis

Size: 9040*2550*3400mm
Wheelbase:1700+3450+1350mm
Rated Power: 240KW
Max. Overall Weight: 31000KG
Max. Speed: 85 km/h
Passenger Capacity: 2

EQ1180EVJ1 | Pure Electric Chassis

EQ1180EVJ1 | Pure Electric Chassis

Size: 8350*2430*3400/3300/3245/3185mm
Wheelbase: 4500mm
Rated Power: 100KW
Max. Overall Weight: 18000KG
Max. Speed: 89 km/h
Rated Capacity: 2,3
